EYM TYPE - SEALING FITTINGS

Conduit fittings are used for an electrical conduit system from the overhead service entrance to machinery, and final electrical outlets. Conduit fittings are generally installed by electricians at the site of installation of electrical equipment.


Conduit sealing fittings are installed in conduit runs to prevent the passage of gases, vapors or flames from one portion of the electrical installation to another through the conduit, limiting any explosion to the enclosure and preventing pre-compression or “pressure piling.”

EYM TYPE - SEALING FITTINGS

TS certificated


規格
Size
(IN)

鑄鐵合金
Feraloy Iron

可鍛鑄鐵

Malleable Iron

球墨鑄鐵

Ductile Iron

表面處理
Standard
Finishes

鋁合金
Aluminum Alloy

尺寸

Dimensions

型號
Cat. No.

型號
Cat. No.

型號
Cat. No.

A

B

C

1/2

EYM 16

EYM16-M

電鍍鋅
Zinc
Electroplate
熱浸鋅
H.D.
Galvanize

達克銹

Dacrotizing

EYM16-A

84

31

41

3/4

EYM 22

EYM22-M

EYM22-A

95

38

48

1

EYM 28

EYM28-M

EYM28-A

111

46

60

1 1/4

EYM 36

EYM36-M

EYM36-A

129

53

45

1 1/2

EYM 42

EYM42-M

EYM42-A

144

61

52

2

EYM 54

EYM54-M

EYM54-A

164

78

59

2 1/2

EYM 70

EYM70-M

EYM70-A

195

90

68

3

EYM 82

EYM82-M

EYM82-A

216

107

84

4

EYM104

EYM104-M

EYM104-A

250

130

94
