PLICA BUSHING-BP - 軟管用接頭
單位:±3mm
|
型號 CAT NO |
公稱管徑 CONDUIT SIZE |
P |
H |
D1φ |
D2φ |
|
BP-17# |
PF 1/2 (16) |
12.5 |
16.5 |
16.3 |
26.3 |
|
BP-24# |
PF 3/4 (22) |
13.5 |
17.5 |
23.3 |
33.3 |
|
BP-30# |
PF 1 (28) |
14.5 |
19.5 |
28.8 |
40.8 |
|
BP-38# |
PF 1 1/4 (36) |
16.0 |
21.0 |
37.1 |
48.1 |
|
BP-50# |
PF 1 1/2 (42) |
16.0 |
22.0 |
48.6 |
61.0 |
|
BP-63# |
PF 2 (54) |
18.0 |
24.0 |
62.8 |
75.0 |
|
BP-76# |
PF 2 1/2 (70) |
22.0 |
29.0 |
76.8 |
90.0 |
|
BP-83# |
PF 3 (82) |
24.0 |
31.0 |
80.5 |
99.0 |
