PULL BOXES

Conduit fittings are used for an electrical conduit system from the overhead service entrance to machinery, and final electrical outlets.

Conduit fittings are used for an electrical conduit system from the overhead service entrance to machinery, and final electrical outlets. Conduit fittings are generally installed by electricians at the site of installation of electrical equipment.


單位:±3mm

規格
Size
(IN)

鑄鐵合金
Feraloy Iron

表面處理
Standard
Finishes

鋁合金
Aluminum Alloy

尺寸

Dimensions

型號
Cat. No.

型號
Cat. No.

 A

B

C

D

1/2

LSC 16

電鍍鋅
Zinc
Electroplate
熱浸鋅
H.D.
Galvanize

達克銹

Dacrotizing

LSC 16-A

250

60

406

152

3/4

LSC 22

LSC 22-A

250

60

406

152

1

LSC 28

LSC 28-A

355

81

603

250

1-1/4

LSC 36

LSC 36-A

355

81

603

250

1-1/2

LSC 42

LSC 42-A

552

125

952

406

2

LSC 54

LSC 54-A

552

125

952

406

2-1/2

LSC 70

LSC 70-A

752

143

1358

610

3

LSC 82

LSC 82-A

752

143

1358

610

4

LSC104

LSC104-A

1150

184

2098

965




(尺寸表僅供參考;實際尺寸以實體為主)
