UNIVERSAL SERVIT - CONDUIT FITTINGS
Conduit fittings are used for an electrical
conduit system from the overhead service entrance to machinery, and final
electrical outlets. Conduit fittings are generally installed by electricians at
the site of installation of electrical equipment.
單位:±3mm
|
CATALOG NUMBER |
CONDUCTOR |
|||||
|
COPPER |
MAXIMUM |
|||||
|
RANGE FOR EQUAL RUN AND TAP |
MIN. TAP WITH MAX RUN |
COPPERWELD |
||||
|
SOL |
STR |
TYPE A |
TYPE D |
|||
|
KS90 |
12 STR-10 STR |
16 STR |
#10 |
- |
- |
- |
|
KS15 |
10 STR-8 STR |
14 STR |
#8 |
- |
- |
- |
|
KS17 |
8 STR-6 SOL |
14 STR |
#6 |
3 # 12 |
8A |
91/2D |
|
KS17-3” |
8 STR-6 SOL |
14 STR |
#6 |
3 # 12 |
8A |
91/2D |
|
KS20 |
8 STR-4 SOL |
14 STR |
#4 |
3 # 10 |
6A |
8D |
|
KS20-3” |
8 STR-4 SOL |
14 STR |
#4 |
3 # 10 |
6A |
8D |
|
KS22 |
6 STR-2 SOL |
14 STR |
#2 |
3#8 |
4A |
6D |
|
KS22-3” |
6 STR-2 SOL |
14 STR |
#2 |
3#8 |
4A |
6D |
|
KS23 |
6 STR-2 STR |
14 STR |
#1 |
3#7 |
3A |
5D |
|
KS25 |
4 STR-1/0 STR |
14 STR |
2/0 |
3#5 |
2A |
4D |
|
KS26 |
2 STR-2/0 STR |
14 STR |
3/0 |
7#7 |
- |
- |
|
KS27 |
1 STR-3/0 STR |
8 SOL |
- |
- |
- |
- |
|
KS29 |
1 STR-250 |
8 STR |
4/0 |
7#5 |
- |
- |
|
KS31 |
1/0 STR-350 |
1/0 STR |
- |
19#8 |
- |
- |
|
KS34 |
2/0 STR-500 |
2/0 STR |
- |
19#6 |
- |
- |
|
KS39 |
4/0 STR-750 |
4/0 STR |
- |
19#5 |
- |
- |
|
KS44 |
300-100 |
4/0 STR |
- |
- |
- |
- |
